8mm/10mm Width Waterproof COB LED Flexible Strip Light UL Certified 320LEDs 4000K Colour Temperature
Product Details:
| Place of Origin: | China |
| Brand Name: | ADLED |
| Certification: | UL/CE/RoHS |
| Model Number: | ADS-YCOB-320-5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100M |
|---|---|
| Packaging Details: | 5m(16.4ft) Per Roll |
| Delivery Time: | 7days |
| Payment Terms: | T/T, Western Union, L/C, D/A, D/P, MoneyGram |
| Supply Ability: | 100000M |
|
Detail Information |
|||
| Name: | USB Powered 320Chips/m COB LED Tape Light | Model: | ADS-YCOB-320-5 |
|---|---|---|---|
| Voltage: | DC5V | LEDs Per Metre: | 320 |
| Watts Per Metre: | 5W | Colour Temperature: | 2700K/3000K/4000K/5000K/6500K |
| IP Rating: | IP20/IP65/IP67/IP68 | Beam Angle: | 180° |
| Warranty: | 3 Years | PCB Width: | 8mm |
| Highlight: | 320LEDs COB LED Flexible Strip Light,4000K COB LED Flexible Strip Light,8mm COB LED Flexible Strip Light |
||
Product Description
Outdoor Waterproof COB LED Flexible Strip Light - UL Certified, 8mm/10mm Width, 320LEDs, FCOB Technology.
Benefits of COB LED Strip 5v
1. Dotless
With COB LED strip lights, there are no visible dots between the LEDs due to their Chip-On-Board technology. The close packing of LED chips creates a dotless and uniform light output, resulting in a smoother and more seamless lighting experience. This design allows for consistent light distribution, making it ideal for various indoor and outdoor lighting applications where uniformity and high performance are desired.
2. More Flexible PCB LED Strip
The Chip On Board technology used in COB LED strips allows for superior flexibility, even in small bend radii. This makes them ideal for use in applications where flexible lighting is necessary, such as curved or irregularly shaped surfaces.
|
3. 180° Beam Angle Chinese LED COB strip lights have a more extensive 180-degree beam angle, producing wider light coverage, compared to traditional strip lights with only a 120-degree beam angle. This wider angle results in a more uniform brightness of tape lights LED, evenly illuminating the desired area. |
|
4.Wider Beam Angle
COB strip lights have several advantages, including uniform light color, high transmittance, no dark areas, and a long lifespan. With a beam angle of up to 180° and a luminous efficacy of up to 100Im/W, these strips are ideal for both indoor and outdoor lighting applications. Their high efficiency and durability make them an excellent choice for commercial and residential lighting needs.
5.Environmental friendliness
COB LED strips are more environmentally friendly than standard LED strips because they don't contain mercury
LED Strip Light Manufacturer
|
Adled Light is a top-tier LED strip light manufacturer in China, specializing in bedroom light strips. We have a dedicated R&D team that develops three new LED tape designs every month, ensuring that we always offer up-to-date and innovative products. We are committed to providing our customers with high-quality LED light strips and offer a warranty period of 3 to 5 years, giving you peace of mind and ensuring long-lasting performance. |
|
What is COB LED Strip?
Chip on board (COB) is a method of circuit board manufacturing in which the integrated circuits (e.g. microprocessors) are wired, bonded directly to a printed circuit board, and covered by a blob of epoxy. By eliminating the packaging of individual semiconductor devices, the completed product can be more compact, lighter, and less costly. In some cases, COB construction improves the operation of radio frequency systems by reducing the inductance and capacitance of integrated circuit leads.
COB LED Strip Specifications:
| Model | ADS-YCOB-320-5 |
| LED type | COB (Chip On Board) |
| LEDs per metre | 320 |
| Operating voltage | DC5V |
| Watts per metre | 5W |
| Colour temperature | 2700K/3000K/4000K/5000K/6500K |
| IP rating | P20/IP65/IP67/IP68 |
| PCB width | 10mm |
| Cut points | 12.5mm(0.49'') for 5V |
| Beam angle | 180° |
| Warranty | 3 Years |
| Certifications | UL/CE/RoHS/ErP |
| Package | 5m(16.4ft) per roll |
| Dimmable |
0-100% dimmable by LED strip light dimmer |
1. COB LED strip lights use Chip-On-Board (COB) technology.
2. Multiple LED chips are mounted directly on a substrate, creating a high density of LEDs on a small surface.
3. COB LED strips emit light that appears as a continuous strip of uniform light with no noticeable dark spots or gaps, providing a smooth and pleasant lighting effect.
COB LED Strip Application:
COB LED Strip FAQ:
Q: Why more and more people choose COB LED tape?
COB LED tape has many big advantages compared with SMD LED strip, such as perfect linear lighting effect, more flexibility, etc. With advanced craft, it can produce more perfect CRI and color temperature values.
Q: Can you link LED strip lights?
Yes, you can link LED strip lights easily. We can provide lots of LED strip accessory, 10mm LED strip connector, 8mm LED strip connector for 528chips COB LED strip.
Q: Is COB LED strip dimmable ?
Yes, you can dim these dimmable COB LED strip with a simple LED dimmer.
Q: Can you make waterproof COB LED strip?
Yes, we can make waterproof COB LED strip IP65, IP67, IP68 for different lighting applications.
Q: Do COB LED strip need aluminum profile for heat dissipation?
An LED aluminum profile can help to draw heat away from the COB light strip, which can prolong the lifespan of the light strip and keep it working at maximum efficiency. The aluminum profile acts as a heatsink, helping to dissipate excess heat that might otherwise damage the LED chips over time.
