DC 24V 320 LEDs Per Meter Tunable LED Strip for Commercial and Residential Lighting Applications
Product Details:
| Place of Origin: | China |
| Brand Name: | ADLED |
| Certification: | UL/CE/RoHS |
| Model Number: | ADS-YCOB-320-24/12 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100M |
|---|---|
| Packaging Details: | 5m(16.4ft) Per Roll |
| Delivery Time: | 7days |
| Payment Terms: | T/T, Western Union, L/C, D/A, D/P, MoneyGram |
| Supply Ability: | 100000M |
|
Detail Information |
|||
| Name: | USB Powered 320Chips/m COB LED Tape Light | Model: | ADS-YCOB-320-12/24 |
|---|---|---|---|
| Voltage: | DC24V/12V | LEDs Per Metre: | 320 |
| Watts Per Metre: | 5W | Colour Temperature: | 2700K/3000K/4000K/5000K/6500K |
| IP Rating: | IP20/IP65/IP67/IP68 | Beam Angle: | 180° |
| Warranty: | 3 Years | PCB Width: | 8mm |
| Highlight: | DC 24V Tunable LED Strip,Residential Lighting Tunable LED Strip |
||
Product Description
DC 24V, 320 LEDs Per Meter, Uniform Light Diffusion, Ideal for Commercial and Residential Lighting Applications.
Benefits of COB LED Strip
1. Dotless
With COB LED strip lights, there are no visible dots between the LEDs due to their Chip-On-Board technology. The close packing of LED chips creates a dotless and uniform light output, resulting in a smoother and more seamless lighting experience. This design allows for consistent light distribution, making it ideal for various indoor and outdoor lighting applications where uniformity and high performance are desired.
2. More Flexible PCB LED Strip
The Chip On Board technology used in COB LED strips allows for superior flexibility, even in small bend radii. This makes them ideal for use in applications where flexible lighting is necessary, such as curved or irregularly shaped surfaces.
3. LED Light Strips Safety
LED strip lights with USB connector can be easily connected to a computer using a 5V plug, providing a simple and convenient way to power and control the lights. This makes them ideal for use in various applications such as computer screen backlighting, desk lighting, and other DIY lighting projects.
|
4. 180° Beam Angle Chinese LED COB strip lights have a more extensive 180-degree beam angle, producing wider light coverage, compared to traditional strip lights with only a 120-degree beam angle. This wider angle results in a more uniform brightness of tape lights LED, evenly illuminating the desired area. |
|
5.Wider Beam Angle
COB strip lights have several advantages, including uniform light color, high transmittance, no dark areas, and a long lifespan. With a beam angle of up to 180° and a luminous efficacy of up to 100Im/W, these strips are ideal for both indoor and outdoor lighting applications. Their high efficiency and durability make them an excellent choice for commercial and residential lighting needs.
LED Strip Light Manufacturer
|
Adled Light is a top-tier LED strip light manufacturer in China, specializing in bedroom light strips. We have a dedicated R&D team that develops three new LED tape designs every month, ensuring that we always offer up-to-date and innovative products. We are committed to providing our customers with high-quality LED light strips and offer a warranty period of 3 to 5 years, giving you peace of mind and ensuring long-lasting performance. |
|
What is COB LED Strip?
COB LED strips eliminate hot spots due to their seamless illumination. Therefore, they are best suited for cases where you cannot hide the LED strip behind anything and do not want to see the individual chips. For this reason, COB strips are commonly used in situations where the light strip is placed close to a reflective surface since it will not show any hotspots in the reflection. Other popular applications include under-cabinet lighting, jewelry/display case lighting, and toe kick lighting.
COB LED Strip Specifications:
| Model | ADS-YCOB-320-24/12 |
| LED type | COB (Chip On Board) |
| LEDs per metre | 320 |
| Operating voltage | DC24V/12V |
| Watts per metre | 5W |
| Colour temperature | 2700K/3000K/4000K/5000K/6500K |
| IP rating | P20/IP65/IP67/IP68 |
| PCB width | 10mm |
| Cut points | 12.5mm(0.49'') |
| Beam angle | 180° |
| Warranty | 3 Years |
| Certifications | UL/CE/RoHS/ErP |
| Package | 5m(16.4ft) per roll |
| Dimmable |
0-100% dimmable by LED strip light dimmer |
COB LED Strip Application:
COB LED Strip FAQ:
Q: Why more and more people choose COB LED tape?
COB LED tape has many big advantages compared with SMD LED strip, such as perfect linear lighting effect, more flexibility, etc. With advanced craft, it can produce more perfect CRI and color temperature values.
Q: Can you link LED strip lights?
Yes, you can link LED strip lights easily. We can provide lots of LED strip accessory, 10mm LED strip connector, 8mm LED strip connector for 528chips COB LED strip.
Q: Is COB LED strip dimmable ?
Yes, you can dim these dimmable COB LED strip with a simple LED dimmer.
Q: Can you make waterproof COB LED strip?
Yes, we can make waterproof COB LED strip IP65, IP67, IP68 for different lighting applications.
Q: Do COB LED strip need aluminum profile for heat dissipation?
Yes, LED aluminum profile can help COB light strip to dissipate heat better and prolong the life of the COB light strip.
