High CRI90 Flex 320leds Reel To Reel COB LED Strip DC24V 21W/M COB Led Linear Strip Light
Product Details:
| Place of Origin: | China |
| Brand Name: | ADLED |
| Certification: | UL/CE/RoHS |
| Model Number: | ADS-YCOB-320-12/24 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100M |
|---|---|
| Packaging Details: | 5m(16.4ft) Per Roll |
| Delivery Time: | 7days |
| Payment Terms: | T/T, Western Union, L/C, D/A, D/P, MoneyGram |
| Supply Ability: | 100000M |
|
Detail Information |
|||
| Name: | USB Powered 320Chips/m COB LED Tape Light | Model: | ADS-YCOB-320-24/12 |
|---|---|---|---|
| Voltage: | DC12V/24V | LEDs Per Metre: | 320 |
| Watts Per Metre: | 5W | Colour Temperature: | 2700K/3000K/4000K/5000K/6500K |
| IP Rating: | IP20/IP65/IP67/IP68 | Beam Angle: | 180° |
| Warranty: | 3 Years | PCB Width: | 8mm |
| Highlight: | High CRI90 COB LED Strip,Reel To Reel COB LED Strip,COB Led Linear Strip Light |
||
Product Description
High CRI90 flex 320leds reel to reel COB LED Strip DC24V 21W/M COB led linear strip light
Benefits of COB LED Strip
1. LED Strip Lights NO Dots
The hot spot lights from traditional white LED strip lights with 5v can be harsh on the eyes, while COB soft white LED tape lights emit uniform brightness that shines in one straight line, providing perfect lighting even without an LED Aluminum Profile.
2. More Flexible PCB LED Strip
The COB LED strip consists of 320 chips with a 6500K color temperature, allowing for an ultra-narrow space between two chips. This allows for the COB LED strip to be bent arbitrarily without causing any damages to the strip.
3. LED Light Strips Safety
With USB connector,5v plug in LED strip lights can easy connect to a computer.
|
4. 180° Beam Angle China LED COB strip light emit 180 degree beam angle, traditional strip lights LED emit only 120 degree. More wide view to create a more uniform brightnss of tape lights LED. |
|
5.Types of COB LED Strip
Our waterproof LED strip lighting include IP65 COB LED strip and outdoor LED strip lights IP67.
LED Strip Light Manufacturer
|
Adled Light is a top-tier LED strip light manufacturer in China. Our R&D team designs and develops three new LED tape designs every month, ensuring that our customers can always enjoy an up-to-date selection. We offer a range of light strips with varying chip counts, including 80, 320, 336, 480, 504, 528, 640, 810, 840, and 896 chips to choose from. All of our COB LED strips are dot-free and come with a 3 to 5-year warranty, ensuring longevity and durability. |
|
What is COB LED Strip?
COB LED strip lights are also known as FOB or FCOB LED strips. Most people would associate the letter "F" in the abbreviations with the word "flexible". It sounds pretty reasonable from an end-user perspective. However, technically the names were derived from the flip chip-on-board (FCOB) technology, which is the driving force behind the innovation. In a conventional COB package, an array of LED dies (chips) are wire-bonded with aluminum or gold wires and die-bonded on a metal-core printed circuit board (MCPCB) or ceramic substrate with silver-filled epoxy. The die matrix is then covered with a phosphor silicone mixture to enhance light uniformity, provide wavelength conversion, and to shield the chip array from the environment.
Manufacturing COB LED strip lights eliminates wire bonding and soldering brackets, making the product more stable and providing improved heat dissipation compared to kitchen LED strip lights production with SMD chips.
COB LED Strip Specifications:
| Model | ADS-YCOB-320-24/12 |
| LED type | COB (Chip On Board) |
| LEDs per metre | 320 |
| Operating voltage | DC24V |
| Watts per metre | 5W |
| Colour temperature | 2700K/3000K/4000K/5000K/6500K |
| IP rating | P20/IP65/IP67/IP68 |
| PCB width | 10mm |
| Cut points |
12.5mm(0.49'') |
| Beam angle | 180° |
| Warranty | 3 Years |
| Certifications | UL/CE/RoHS/ErP |
| Package | 5m(16.4ft) per roll |
| Dimmable |
0-100% dimmable by LED strip light dimmer |
COB LED Strip Application:
• Decorate shopping mall, super market
• Club, store, hotel, restaurant, school, library, art gallery, museum
• Office building
• Window display lighting, mirror decoration, Bottle Moulding Machine
• Large scale backlight
• Indoor and outdoor lighting and for festival decoration
COB LED Strip FAQ:
Q: Why more and more people choose COB LED tape?
Compared to SMD LED strips, COB LED tape has many advantages, including a perfect linear lighting effect and increased flexibility. Advanced manufacturing techniques also allow for perfect CRI and color temperature values.
Q: Can you link LED strip lights?
Yes, you can link LED strip lights easily. We can provide lots of LED strip accessory, 10mm LED strip connector, 8mm LED strip connector for 528chips COB LED strip.
Q: Is COB LED strip dimmable ?
Yes, you can dim these dimmable COB LED strip with a simple LED dimmer.
Q: Can you make waterproof COB LED strip?
Yes, we can make waterproof COB LED strip IP65, IP67, IP68 for different lighting applications.
Q: Do COB LED strip need aluminum profile for heat dissipation?
Yes, LED aluminum profile can help COB light strip to dissipate heat better and prolong the life of the COB light strip.
